EU/UK Touch Switch
Multiple colors and Gang to choose for home improvement Enjoy your smart home life
Super touch sensitivity
The high sensitivity experience is the same as pressing the phone
Tempered crystal panel glass
Prevent scratches and scarring not easily deformed and discolored
Tempered Glass and PC Case is Fireproof
Strengthen protection for the short circuit of power line Fireproof rate is V-0
The crystal panel is Moisture proof
The wet hand can operate the panel and the water vapor does not easily enter the inside of the panel
Tempered Glass Panel EASY to Clean
Convenient for maintenance and cleaning with a cloth or tool
On and off the backlight effect
On is red display, Off is blue display
Soft light indicator
The weak blue light will not affect your sleep
The switch is suitable for lamp types
halogen lamps, high pressure sodium lamps, LED lamps, energy-saving lamps, incandescent lamps
Excellent process manufacturing and technology upgrade
How to use capacitors
1. The power needs to be turned off during installation
2. Please connect the “L” position to FireWire correctly
3. Located at the “L1”, “L2” and “L3” positions respectively to control the light bulb
4. The cover can be opened to complete the final process
5. The figure below is the schematic diagram of the capacitor installation: the installed load bulbs are halogen lamps, led bulbs, high-voltage strips, smart led bulbs or bulbs less than 5W, all need to install this yellow safety capacitor, and the capacitors are connected in parallel to control the live and neutral wires
Switch installation video
1. It needs to be powered off during installation
2. Please correctly connect the ‘L’ position to FireWire
3. ‘L1’L2’L3’ respectively position to control the live wire of the bulb
4. The cover panel can be powered on to complete the final process
5. The figure below is a schematic diagram of installing the capacitor: the installed load bulb is a halogen lamp, led bulb, smart bulbs or bulbs less than 5W need to install this yellow safety capacitor, the capacitor is connected in parallel between the control live wire and the neutral wire
Display of different decoration scenes
picture display as an example, there is a difference between the effect picture and the actual display
Product real pictures for example
The color of the product is subject to the actual product
1、1/2/3 Gang touch switch 220v wall Light Switch,EU Standard smart home switch
2、Toughened crystal glass panel design, no fading, looks elegant and stylish.
3、Super sensitivity-Just need touch it light， Waterproof and Resistance Scratch. Protection Against Electric Shock.
4、 Popular Colors are available: Black, White, Golden,
5、With blue LED indicator, very distinguished, more humanization design,The button will glow at night, making it easier to find.
6、New imported IC processor for nice sensitivity and stable performance
7、the base is made of high temperature resistant PC material, making the switch durable and longer life.
8、Single live wire control, easy to install, replace the old switch directly.
9、Touch control ensures longer service life than traditional switch.
10、Protection of over-current, anti-interference，Certification: CE, ROHS, FCC、EU.
11、Easy to clean, panel glass resists deformation and fading.
12、 Elegant look, Suited greatly with many modern decor styles. It can be applied to drawing room, bedroom, corridor, kitchen, bathroom, Office and so on.
1、Brand Name: UBARO
2、Button:1 gang、2gang、3gang for you choose
3、Color: Black, White, Golden
4、Size: 8.6*8.6*3.5cm / 3.4*3.4*1.4″ (L*W*H)
7、Working Voltage: 170V-240 V AC
8、Working Temperature: -20 ℃~+70℃
9、Relative Humidity: 10% ~ 90%
10、Mechanical Life: 100000 Times
11、Certification: CE,CCC ,ROHS
12、Warranty: 1 year
13、Delivery time: <3 days Received your order
14、Gross weight：0.15kg/5.25oz Net weight: 0.14kg / 4.9oz
1*Safety X capacitor
1 * User Manual
1、You have to cut off the power and during the installation.
2、Single firewire design.No need to open the wall rewiring,diret replacement of the old switch.
1、Its Door to Door Shipment. Can send to more than 100+ countries
2、Our products promise to ship within 3 days after receiving your order
3、If you’re from Russia, Please leave your full name. It is very important
4、We choose the official online logistics, which is safe and reliable, and guarantees the fastest timeliness for you to receive your products.
1、Please contact us through aliexpress after order or leave message to us, usually we will respond within 1-2 business days
2、If you want to place a large order for wholesale, please feel free to contact us. -If you need to order multiple items(≥1000usd), pleases let us know first. We might offer you some extra discount.
3、Please check items when delivered, if damaged, please kindly accept it and contact us immediately. We will make a confirmation and give you a solution.
1 years manufacture warranty; -Defective problem should be submitted within 10 business days after product is delivered; -Shipping damage should be submitted within 7 business days after product is delivered.
Any feedback from you will be much appreciated. If you’re satisfied with our service or products, please give us 5 stars. -If you have any questions, please also contact with us, and we will offer help to you sooner. It’s our responsibility to ensure quality.
